Understanding Phone Screen Features
This is what your main phone screen might look like with active calls and several feature menus open.
1 Primary phone
line Displays the phone number (directory number) for your primary phone line.
2 Programmable
button
indicators Programmable buttons can serve as phone line buttons, intercom line
buttons, speed-dial buttons, phone service buttons or phone feature buttons.
Icons and labels indicate how these buttons are configured. For an icon
reference, see the
“Phone Screen Icons” section in the Quick Reference Card at
the front of this guide.
3 Softkey labels Each displays a softkey function.
4 Status line Displays audio mode icons, status information, and prompts.
5 Call activity
area Displays current calls per line, including caller ID, call duration, and call state
for the highlighted line (standard view). See
Understanding Line and Call Icons,
page 13 , and Viewing Multiple Calls, page 27 .
6 Phone tab Indicates call activity.
7 Feature tabs Each indicates an open feature menu. See Understanding Feature Buttons and
Menus, page 17 .
