Be sure to set the stitch width at O, or the
needle will break in striking the foot or plate.
Push the zigzag lever 17, Fig. 13) all the way to the
left so that pointer is over
0 in stitch width window.
Set both locks, 6 , as far to the left as possible.
To move locks, pull knobs slightly and slide, then
release.
SETTING THE STITCH LENGTH
The length of the stitch is regulated by the dial A shown
in Fig. 14. Near 0 is the shortest stitch and 6 is the longest.
Turn the dial to the left to lengthen and to the right to shorten
the stitch.
STITCH LENGTH CHART (Approximate)
Fig. 13
Figures on dial 0 1 2 3 4 5 6
Number of
stitches per inch
No feeding 36 2 0 1 2 9 7 5
13
