Changing The Presser
Feet
1
Remove the presser foot.
(2) Push the presser foot release push
button in the direction of the arrow.
2
Align the presser foot pin with
the marker line.
3
Move the presser foot lifter
down to the horizontal position
and the new foot will snap on.
(When the presser foot lifting lever is set
in the horizontal position, the presser
foot is lowered.)
Types Of Feet And Their Application
Typical
applications
Stitch pattern
Straight stitch
Quilting
Pintuck
!
Stretch
reinforcing stitch
*
H
Standard presser foot
Zigzag stitch
Applique
Quilting
M i l l
Overcasting
3~step zigzag stitch
(elastic stitch)
Overcasting, etc.
A
Patterns on A side
Pattern stitch,
patchwork, etc.
1
93 97
Large size pattern figure
stitch
Patterns on A side
No. 00-19
Decorative stitch fool
Large size alphabetical
stitcti
Large size continuous
pattern stitch
Patterns on A side
No. 47-75
76-79
86-89
T
Standard pattern stitch
Patterns Ofi A side
No. 20-47
80-86
90-97
Patterns on B side
No. 20-79
82-97
Typical
applications
Stitrfi pattern
Zipper foot
Setting zipper
1
B
Overcasting
Stitcti width 5
Overcasting
(Overlocking)
c
Biindstitch presser foot
Biindstitch
D
Buttonhole foot
E
Automatic
buttonlwling
If ь Ы
vS M U
