CLEANING
SHUTTLE
Shuttle driver
Shuttle
Shuttle cover
Bobbin
case
1. Raise needle to its highest position.
2. a. Take , out the bobbin case from the
shuttle.
b.
Turn the two shuttle cover latches
outwards.
c. Take out shuttle cover and thè shuttle.
3. Clean feed dogs and shuttle with brush.
Note: Apply a drop of sewing machine oil
onto the centre stud of shuttle race
as indicated by an arrow
4. a. Be sure the shuttle driver looks as a half
moon on the left side.
Inserting the shuttle in the centre it
should form the other half moon on the
right side.
35
