Transmission Assembiy T-IO & T’ISS
No. Description Part No.
o
t H
H
ra
o
iH
1
H Qty, No. Description Part No.
o
i-i iH
]
Qty.
TRANSMISSION ASSEMBLY LM-160S2-S5 X 1 44 WASHER LM-01540-97
X X 1
TRANSMISSION ASSEMBLY LM-16082-84
X
1 45 WASHER-axle tube LM-01541-30
X X 2
1
COVER-gear case sub assembly LM-01642-26 X X 1 46 GEAR-drive LM-01540-95 X X 1
Includes: 47 SPACER-axle tube LM-01540-98
X X
1
2 BEARING LM-01082-02 X X 1 48 TUBE & BUSHING ASSEMBLY LM-01642-22
X X 1
3 RING-retaining LM-01640-64 X X 1 49 Includes: BUSHING LM-01642-24 X X 1
4 BEARING-needle LM-01542-57 X X
1 50 KEY LM-01540-96 X X 2
5 ROLL PIN ASSEMBLY LM-01545-37
X X
1 51 FITTING-lube LM-09128-08 X X 1
6 BEARING-needle LM-01542-71 X X
1 *52 WASHER LM-01729-77 X X 2
? BEARING-needle LM-01542-59
X X
1 53 SPRING LM-01543-23 X X 2
8 BEAR ING-needle LM-01575-20
X X
1 54 SCREW-hex hd. cap, 3/8-16 x 1- -1/4LM-09174-00 X
1
9 RING-retaining LM-01I81-34
X X
1 55 PIN ASSEMBLY-rev. gear LM-01543-52
X 1
10 GASKET-gear case LM-01642-34 X X 1 56 WASHER LM-01543-25
X
1
11 WASHER LM-01084-72 X X
1 57 SPACER-rev. gear LM-01540-84 X 1
*12 SHAFT-pulley LM-01743-38 X 1 58 GEAR-re verse LM-0154 0-8 7 X 1
SHAFT-pulley LM-01738-07
X
1 59 NUT-hex lock fin. LM-09180-16
X
1
13 KEY LM-01642-94
X X
1 60 SEAL-oil LM-01542-63 X X 1
14 PINION ASSEMBLY LM-01540-75
X X
1 61 STEM-shift LM-01542-61 X X
1
* GEAR-2nd & 4th LM-01742-34
X
1 62 SCREW-hex hd. cap, 5/16-18 x 1 LM-09164-31 X X
14
15 PINION ASSEMBLY-Rev. & H LM-01540-72
X
1 63 WASHER-lock, 5/16 LM-09173-56
X X 14
16 RING-retaining LM-01542-64 X X 2 64 RING-snap LM-01542-68
X X 2
17 WASHER LM-01544-62
X X
1 65 SEAL LM-01542-69
X X 2
*18 NUT-fuU, 3/8-24 LM-09221-32
X X
1 66 PLUG-pipe LM-09016-53 X X 3
19 NUT-hex jam fin, 5/16-18 LM-09201-61 X X 1 67 FORK-shift LM-01540-69 X X 2
*20 PINION-Rev. & IV LM-01742-28
X X
1 68 RING-retaining LM-80610-48
X X 2
21 SPACER LM-01540-82 X X 1 69 SHAFT-shifter, HI-Lo LM-01540-68 X X 1
22 GEAR-driven II LM-01540-81
X X 1 70 CASE-gear sub assembly LM-01575-16 X
1
23 SPACER-transmission gear LM-80610-12 X X 3 * CASE-gear sub assembly LM-01745-82 X
1
24 SHAFT-lst mtrn. LM-01572-90 X X 1 Includes:
25 KEY LM-01543-54 X X 1 SPACER (not shown) LM-01210-84 X 2
26 PINION-driven III LM-01540-80 X X
1 71 ROLL PIN SUB ASSEMBLY LM-01545-38 X X
1
27 ■ PINION-lst Intrm. LM-01540-79
X X
1 * PLUG-expans ion (not shown) LM-01745-83 X
1
*28 BOLT-rd.hd., 5/16-18x1 LM-01722-41 X X
1 72 SEAL-oil LM-01576-19
X X 2
29 GEAR-driven 1st LM-01540-78 X X
1 SCREW-set (not shown) LM-09028-70
X
1
30 ROD-shift LM-01642-50
X X
1 73 PIN-roll LM-09181-13 X X 2
31 WASHER LM-01540-38 X X 1 74 BEARING-needle LM-01575-19 X X
1
32 SPACER LM-01540-90
X X
1 75 BEARING-needle LM-01542-59 X 2
33 KEY LM-01542-6 7 X X 1 BEARING-needle LM-01542-59
X 3
34 SHAFT-2nd. intermediate LM-01540-86 X X 3 76 BEARING-needle LM-01542-57 X X
1
35 GEAR-2nd. intermediate LM-01540-89
X X 3 77 BEARING-needle LM-01542-58 X X
1
36 PINION-2nd. intermediate LM-01640-62
X X
1
78 SHAFT-shifter rev. med. LM-01540-67 X X
1
37 RING-retaining LM-01542-66
X X
2
79 BALL-shift lock LM-01542-62 X X 2
38 . SCREW-set soe. hd., 5/16-18x 1/2LM-09172-31 X X 2
*80 WASHER LM-01729-79
X X 4
39 GEAR-3rd. intermediate LM-01640-51 X X 1
*81 WASHER LM-01729-78 X 3
40 KEY-Woodruff #6 LM-09102-24
X X 2
WASHER LM-01729-78
X
4
41 PIKION-3rd. intermediate LM-01540-92 X X 1
*82 WASHER LM-01729-82 X X 1
42 SHAFT-3rd. intermediate LM-01540-91
X X
1
*83 WASHER LM-01729-81
X X 1
43 SUPPORT-s witch LM-01642-51 X X
1
84 ELBOW-street LM-09017-23 X
1
* Denotes new parts
ALWAYS FURNISH MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.
