Shuttle Drive
No.
Description
Part No.
Qty.
PLANETARY ASSEMBLY
Includes:
LM-01762-56
1
*
2
PLANETARY CARRIER
Includes:
LM-01745-86
1
=*= 3
BEARENG-flanged
LM-01737-89
1
* 4
PINION-differential assembly
Includes:
T,M-01762-.57
4
* 5
BEARING-needle
LM-01745-67
8
*
6
BEAR ING-s lee ve
LM-01745-69
4
* 7
"0" Ring
LM-01743-99
2
* 8
COVER-differential
LM-01744-04
2
* 9
PIN“pinion
LM-01740-2 5
4
’t'lO
WASHER-lock shakeproof, 5/16
LM-09233-00
8
11
NUT-hex full, 5/16 X 18
LM-09173-72
12
12
SCREW-hex cap, 5/16-18 x 2
LM-09193-54
4
13
WASHER-lock, 5/16
LM-09173-56
4
*14
WASHER-thrust
LM-01742-74
1
*15
GEAR-differential
LM-017 57-14
1
*16
CAP-hub
LM-01745-84
1
*17
PULLEY ASSEMBLY
Includes:
LM-01762-55
1
*18
PULLEY
LM-01737-94
1
*19
GEAR-sun
LM-01757-12
1
*20
SEAL
LM-01749-81
1
*21
BEARING-roiler seal
LM-01745-92
1
*22
INNER-race
LM-01745-68
1
*23
BEARING-thrust
LM-01745-70
1
24
KEY-Woodruff #9
LM-09051-23
1
*25
PULLEY-half
LM-01737-93
1
*26
BRAKE BAND ASSEMBLY
LM-01743-81
1
*27
ROD
LM-01743-85
1
28
PIN-cotter
LM-09184-47
4
29
PIVOT
LM-01081-72
1
30
SCREW-hex cap, 3/8-16 x 1-1/2
LM-09193-50
3
31
WASHER-lock, 3/8
LM-09169-65
6
32
WASHER-plain, 5/16
LM-09176-42
2
*33
BRAKE-anchor
LM-01743- 86
1
34
SCREW-hex cap, 3/8-16 x 1
LM-09212-10
1
35
PIN-quick
LM-01067-37
1
*36
LEVER
LM-01744-27
1
37
NUT-hex full, 3/8-16
LM-09169-50
4
38
WASHER-plain, 3/8
LM-09173-7 8
5
*39
BUSHING
LM-01180-92
2
*40
LEVER ASSEMBLY
LM-01738-64
1
41
GUIDE-belt
LM-01744-02
1
42
SPACER
LM-01748-70
1
43
PULLEY-idler
LM-01745-61
1
*44
PULLEY
LM-01743-59
1
45
KEY-hi pro, 3/16 X 3/4
LM-09221-39
2
46
NUT-jam lock, 3/4-16
LM-16070-21
2
*47
"V" Belt
LM-01747-31
1
*48
"V" Belt ■
LM-01748-83
1
49
SCREW-Taptite hex hd. 5/16-18 x 1/2
LM-09248-56
2
*50
GUARD ASSEMBLY PULLEY
LM-01743-94
1
*51
GUARD ASSEMBLY-belt
LM-16078-98
1
52
BOLT-carriage, 3/8-16 x 1
LM-09077-31
1
*53
GUIDE-belt
LM-01067-17
1
54
PULLEY
LM-01744-97
1
55
"E" Ring
LM-16021-55
1
*56
LEVER ASSEMBLY IDLER
LM-01738-61
1
*57
LINK-clutch
LM-01640-88
1
* Denotes new parts
ALWAYS FURNISH MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.
