Clutch,Brake
&
Dual Range T-IO
m
No.
Description
Part No.
Qty.
22
WASHER-flat
LM-09246-07
2
23
PULLEY
LM-16065-54
1
24
NUT-hex lock, 3/8-16
LM-09234-28
2
25
WASHER-flat
LM-09176-42
1
26
SPRING
LM-16107-03
1
27
BRAKE-sheave
LM-16105-90
1
28
PIN-cotter
LM-09193-13
1
*29
ROD-pulley brake
LM-16086-21
1
30
SCREW-hex hd. cap, 5/16-18 x 2-1/2
LM-09193-55
1
31
KEY-Hi Pro
LM-09051-23
1
32
NUT-hex lock, 5/16-18
LM-09233-62
4
*33
SPACER
LM-16083-10
3
34
NUT-lock jam, 3/4-16
LM-16070-21
2
*35
SHEAVE
LM-16081-22
1
*36
RETAINER ASSEMBLY-rear
LM-16081-27
1
*37
RETAINER ASSEMBLY, belt
LM-16083-08
1
*38
V-BELT-dual range drive
LM-16079-67
2
*39
HUB-puUey
LM-16083-09
1
*40
SHEAVE
LM-16081-23
1
*41
PULLEY-front
LM-16083-22
1
42
SCREW-hex, 5/16-18 x 2
LM-09193-54
3
*43
CUP-spring'
LM-01748-93
1
44
SCREW-hex washer, 5/16-18 x 1/2
LM-09248-56
3
*45
PEDAL ASSEMBLY-foot
LM-01711-78
1
46
BUSHING-flanged
LM-16104-56
4
47
ARM-foot pedal
LM-16064-77
1
48
WASHER-3/8
LM-09173-78
2
49
WASHER-lock, 3/8
LM-09169-65
4
50
SPRING-break pedal
LM-01591-06
1
51
ROD-clutch & brake
LM-16064-78
1
52
ROD-shift assembly
LM-16064-49
1
53
BALL-shift lever
LM-16010-42
2
54
SCREW-hex hd. cap
LM-09261-50
1
55
LEVER ASSEMBLY
LM-16066-12
1
*56
PIN
LM-16087-02
1
57
PIN-cotter
LM-09184-47
1,
*58
SUPPORT-belt retainer
LM-16083-04
ll
59
LINK-speed control
LM-16065-48
1
60
LEVER-parking brake
LM-01721-08
1
61
NUT-hex lock. 1/4-20
LM-09233-58
1
62
SCREW-hex hd. cap, J/4-20 x 1-1/4
LM-09287-45
1
63
END-rod
LM-01719-94
1
64
ROD ASSEMBLY-control
LM-16060-15
1
65
SPRING
LM-01210-37
1
66
ROD-brake
LM-01641-89
1
67
PIN-cotter
LM-09184-48
1
68
ROD ASSEMBLY-parking brake
LM-16069-03
1
69
FORK-shift
LM-16065-67
1
70
SCREW-hex hd. cap, 3/8-16 x 2
LM-09174-02
1
71
NUT-hex, 10-24
LM-09166-21
1
72
"E” RING-external
LM-16027-35
2
*73
S PRING- tens ion
LM-01748-96
1
74
WASHER-lock, #10
LM-09173-65
1
75
SCREW-flat, 10-24 x 5/8
LM-09262-67
1
*76
LEVER ASSEMBLY-pivot
LM-16083-17
1
77
GUIDE ASSEMBLY-rod
LM-16 043-19
1
*78
STRAP-pulley brake
LM-16079-43
1
79
SCREW-hex hd. cap, 7/16-14 x 1-1/4
LM-09206-77
1
80
SPRING
LM-01570-41
1
ALWAYS FURNISH MODEL AND SERIAL NUMBER WHEN ORDERING PARTS.
