SECTIONS. LEARN THE STITCHES
Set the Machine
Stitch width
controi 2
2
3
0
Top thread tension
controi 2 to 6
Buttonhole toot
Helpful Hints
You can obtain best results to use
#60 ~ #80 light weight threads as
bobbin thread.
NOTE; It is advisable to use a blue
stretch fabric needle when
sewing knits and synthetic
fabrics.
You can obtain buttonholes
With a wider cutting space by
setting
the
stitch
width
control at 1.5 instead of 2.
b.
Raise the needle to its highest position.
c.
Remove the foot holder.
d.
Pull bobbin thread out about 3" straight back toward rear of machine.
e.
Insert hook of base plate into rectangular hole of needle plate.
f.
Pull lever back to align the hook with the rectangular hole.
g.
Snap base plate down to fit two pins {A) at the back of base plate into
two round holes (B) on needle plate.
Release lever.
45
