SECTIO\: 2. PREPARE YOUR''v-iACHlNE FOR SEWI\'G
Prepare the Bobbin
To Remove the Bobbin from the Machine
Wind the Bobbin
1.
Gently push down on the bobbin cover plate and slide
It
towards you.
2.
Set aside.
3.
Lift out the bobbin, as shown.
NOTE: The bobbin winder stopper can be adjusted for
the amount of thread needed on the bobbin
(example 1/ 2 full or full etc.K To make the
adjustment use your large screw driver and
loosen the screw one turn or less. This will allow
you to adjust the position of bobbin winder
stopper. Do not take screw all the wayout.
Bobbin winding spindle
^Clutch
1.
Put your spool of thread onto spool pin, with the thread winding in the direction
shown.
2.
Puli the clutch away from the machine to stop the needle from moving while you
winding the bobbin.
3.
Draw thread from spool through bobbin winder tension disc as shown.
4.
Place the threaded bobbin on the bobbin winding spindle so that the thread comes
out on top.
5.
Push the bobbin winder spindle to the right until it clicks.
6.
Holding onto end of thread, depress the foot control.
7.
When the bobbin is slightly filled, stop the machine and clip the thread coming from
the bobbin.
8.
Slowly start the machine again and wind the thread until the bobbin stops.
9.
Push the bobbin winder spindle to the left and clip the thread.
10.
Remove the bobbin.
11.
Push in the clutch for normal sewing operation.
15
