SEARS CRAFTSMAN 5.5 H.P. ENGINE MODEL NO. 143.965501
FOR CHIPPER-VACUUM MODEL NO. 247.799630
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1 36718 Cylinder (Incl. 2, 20 & 72) 126 29315C Intake Valve (1/32" O.S.)
2 26727 Dowel Pin (Incl. 151)
4 32678 Oil Drain Extension 130 650912 Screw, 5/16-18 X 1-1/2"
5 30969 Extension Cap 130A 650999 Screw, 5/16-18x2-41/64"
14 28277 Washer 135 34645 Resistor Spark Plug (N4C)
15 30589 Governor Rod 150 31672 Valve Spring
16 36618 Governor Lever 151 31673 Valve Spring Cap
17 36700 Governor Lever Clamp 153 36649 Push Rod Guide
18 650548 Screw, 8-32 x 5/16" 154 650913 Rocker Arm Stud
30 36831 Crankshaft 155 35624A Rocker Arm
35 29826 Screw, 10-32x3/4" 157 650914 Nut, 1/4-28
36 29918 Lock Washer 158 36629 Push Rod
37 29216 Lock Nut, 10-32 159 35626 Rocker Arm Cover Gasket
38 29642 Retaining Ring 160 36630A Rocker Arm Cover
40 40004 Piston, Pin & Ring Set (Sid.) 161 651008 Screw, 1/4-20 x 31/64"
40 40005 Piston, Pin & Ring Set (.010" O.S.) 161A 651012 Stud
41 36070 Piston & Pin Ass’y- (Std.) (Incl. 43) 173 36675 Breather Tube
41 36071 Piston & Pin Ass’y. (.010" O.S.) 178 650852 Nut, 1/4-20
(Incl. 43) 182 650451 Screw, 1/4-20 x 1"
42 40006 Ring Set (Std.) 184 26756 Carburetor to Intake Pipe Gasket
42 40007 Ring Set (.010" O.S.) 185 36631 Intake Pipe
43 20381 Piston Pin Retaining Rinc 207 36632 Throttle Link
45 32875A Connecting Rod Ass’y. 223 650451 Screw, 1/4-20 x 1"
(Incl. 46 & 49) 224 36581 Intake Pipe Gasket
46 3261OA Connecting Rod Bolt 238 28820 Screw, 10-32 X 1/2"
48 35616 Valve Lifter 239 27272A Air Cleaner Gasket
49 36611 Oil Dipper 240 36633 Air Cleaner Body (Incl. 239)
50 36725 Camshaft 245 36046 Air Cleaner Filter
64 651015 Screw, 1/4-20 x 1-1/8" 245A 36634 Air Cleaner Filter (Poly)
69 36624 Cylinder Cover Gasket 250 36635 Air Cleaner Cover
70 36724 Cylinder Cover (Incl. 751 iru 83) 251 650886 Wing Nut
72 27642 Oil Drain Plug 252 650821 Screw, 10-32
X
1/2"
75 27897 Oil Seal 275 36722 Muffler
76 30318 Oil Seal 277 651009 Screw, Torx T-30, 1/4-20 x 2-9/32"
80 30574A Governor Shaft 278 36674 Spacer
81 30590A Washer 279 650852 Nut & Lock Washer
82 30591 Governor Gear Ass’y. (In :l. 81) 280 36642 Heat Shield
83 36057 Governor Spool 305 35554 Oil Fill Tube
86 650488 Screw, 1/4-20
X
1-1/4" 307 35499 “0’’-Ring
89 610961 Flywheel Key 308 36651 Fill Tube Clip
119 36719 Cylinder Head Gasket 309 651011 Screw, 10-32x5/16"
120 36721 Cylinder Head 310 36640 Dipstick
125 36471 Exhaust Valve (Std.) (Inc . 151) 380 640025 Carburetor (Incl. 184)
125 36472 Exhaust Valve (1/32" O.f i.) 416 36085 Spark Arrestor Kit (Incl. 417)
(Incl. 151) 417 650760 Screw, 8-32 x 3/8"
126 29314B Intake Valve (Std.) (Incl. 151)
