SEARS CRAFTSMAN 5.5 H.P. ENGINE MODEL NO. 143.965501
FOR CHIPPER-VACUUM MODEL NO 247.799630
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1
36710 Extension Spring 22 650821 Screw, 10-32 X 1/2"
2 32600 Oil Seal 26 36638 Control Knob
3 36621 Air Baffle (Left) 28 36753 Blower Housing
4 36622 Air Baffle (Right) 29 651008 Screw, 1/4-20 x 31/64" Thd.
5 30200 Screw, 10-24 x 9/16" Thd. 30 650821 Screw, 10-32 x 1/2"
6 36623 Blower Housing Extensior 32 35985B Starter Cup
7 650760 Screw 8-32 x 3/8" Thd. 33
—
Rivet (Can Be Purchased Locally)
8 28545 Grommet 34 30705 Fuel Line
10 33356 Ground Terminal 35 26460 Fuel Line Clamp
11 611205 Flywheel 36 36752 Fuel Tank
12 650815 Belleville Washer 37 36246 Fuel Cap
13 650816 Flywheel Nut 38 34080 Spacer
14 34443A Solid State Ignition 39 33177 Terminal
15 610118 Spark Plug Cover 40 29443 Wire Clip
16 651007 Torx ScrewT-15, 10-24x15/16" 41 36644 Fuel Tank Bracket
Thd. 42 651010 Screw, 1/4-20 x 7/8" Thd.
17 36681 Ground Wire 43 36261 Lubrication Decal
18 36054 Ground Wire 44 33107 Speed Control Decal
19 36711 Governor Link 46 590736 Rewind Starter
20 36712 Control Bracket 47 36720 Gasket Set
21 610973 Terminal
