Repair Parts
PARTS UST FOR CRAFTSI\i1A?^ 10" MITER SA'#S
MODEL MO. 113.235220 & 113.235240 AND 113.235110
FIGURE 2-^-^ARM AND MOTOR ASSEMBLY ,
0^^
13
fe. rm
‘15
10
WARNING: For your safety, this miter saw is specially insulated. To avoid electrical shock, fire or injury, use
only parts identical to those identified in the parts list. Reassemble exactly as originally assembled.
Always order by Part Number — Not by Key Number
Key
No.
Part
No.
Description
1 823290 Handle Right Half
2 808380-5 * Screw Pan Cr #8 Plastite
3 823286 «a * Switch SPOT
823289 Spring Trigger
5 823287 A Trigger
6 823281 M Brush
7 823277 M Holder Brush
0 354653 , Bumper
9 823955 “ ‘AMotor/Gear Box
8 823841 is »aMotor/GearSox
10 q O'IKIOQ
0 ¿2. 0 xJ dL 0 ALock Arbor
11 823322 ASpring Arbor Lock
12 823417 . Seal
13 823284 m *ACord W/Plug
13 823284” 1 ik flCordW/Plug
14 803709-1 . Connector Wire
15 823288 A Button Lock
16 823283 Cap Motor Housing
17 808277-11 Screw Pn Hd. 10-32X
2-1/4
18 STD551210 * Lockwasher Ext #10
19 STD551010 • Washer 13/64 x 3/8 x 1/32
A Mode! 113 235220 & 113,235240 Only H Mode! 113 235110 Only
^ WARNING; These items are important to the safety of this tool. Do not substitute common parts.
t
CAUTION; See Mechanical Assembly Caution below.
• WARNING; Any attempt to repair or replace electrical parts on this unit may create a Hazard unless repair
is done by a qualified service technician. Repair service is available at your nearest Sears store.
