SECTION 2. PREPARE THE MACHINE FOR SEWING
Prepare the Bobbin
o To Remove the Bobbin Case from the Machine
Remove the extension table trom
the machine by pulling it to the left.
Open the shuttle cover by pulling
down the embossed part on the left
side of the cover.
Raise needle to its highest position
by rotating hand wheel toward you.
To remove bobbin case from shut
tle, pull open latch of bobbtn.^case.
Pull bobbin case straight out of
shuttle -
0
Wind the Bobbin
while you wind the bobbin.
НОТЕ. The bobbin winder stopper can be adjusted lor the amount of thread needed
on the bobbin (example 1/2 full or full etc.). To make the adjustment use your
large screw driver and loosen the screw one turn or less. This wii! allow you
to adjust the position of bobbin winder stopper. Do not take screw all the
wayoul.
