FULL ONE YEAR WARRA^llf Qivj Qji;i^fr|-SMAN SCROLL SAW
If within one year from the date of purchase this Craftsman Scroll Saw fails due to a defect in material or work­
manship, Sears will repair itfree of charge.
WARRANTY SERVICE IS AVAILABLE BY SIMPLY RETURNING THE CRAFTSMAN SCROLL SAW TO THE
NEAREST SEARS RETAIL7CATALOG STORE OR SERVICE CENTER/DEPARTMENT IN THE UNITED
STATES.
THIS WARRANTY APPLIES ONLY WHILE THIS PRODUCT IS USED IN THE UNITED STATES.
Tfiis warranty gives you specific legal rights and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., D817 WA Hoftmarr Estates, IL. 60179
safety instryctloris for scroll saw
Safety is a combination of common sense, staying alert
and knowing how your scroll saw works. Read this man­
ual to understand this saw.
Safety Signal Words
DANGER: triers if the safety information is not followed
someone will be seriously injured or killed.
WARNING: means if the safety information is not fol­
lowed sonaeone could be seriously injured or killed.
CAUTION: means if the safety information is not followed
someone might be injured.
BEFORE USING THE SAW
WARNING: lb avoid iTii^ that could cause seri­
ous peiThiahertt injury, do not plug the saw in until
the following steps aré completed.__________________
Assembly and alignment (See pages 7-12)
Learn the use and function of the speed control ON-
OFF knob, bevel iock knob, blade holders, blade sup­
port, hold down, tension knob, and blade guard. (See
pages 13-14)
Review and understand all safety instructions and
operating procedures in this manual.
Review of the maintenance methods for this saw. (See
page 18) Read the WARNING label below, found on
the báse of the saw.
WHEN INSTALLING OR MOVING THE SAW
avoid dangerous INViRONMENT. Use the saw In a
dry indoor place, protected from rain. Keep work area
well lighted.
To avoid in|ury from unexpected saw movemeht:
• Turn saw off and unplug cord before rTTOVihg the saw.
• Put the saw on a firm level surface where there is
plenty of room for handling and properly supporting the
workpiece.
• Support the saw so the table is level and the saw does
not rock.
• Bolt the saw to the work surface if it tends to slip, walk,
or slide during operations like cutting long heavy
boards, or whbn using an auxiliary table.
" NEVER STAND ON TOOL, Serious injury could occur
if the tool tips or you accidentally hit the cutting tool. Do
not store anything above or near the tool where any­
one might stand on the tool to reach them.
To avoid injury or death from electrical shock:
* GROUND THE SAW. This saw has an approved 3 con­
ductor cord and a 3-prong grounding the plug, Use
only 3-wire, grounded outlets rated 120 volts, 15
amperes (amps). The green conductor in the cord is
the grounding wire. To avoid electrocution, NEVER
connect the green wire to a live terminal.
• Make sure your fingers do not touch the plug’s metal
prongs when plugging or unplugging the saw
BEFORE EACH USE:
Inspect your saw.
DISCONNECT THE SAW. To avoid injury from accidental
staring, unplug the saw, turn the switch off and remove
the switch key before changing the setup, removing cov­
ers, guards of blade.
MOTOR: 1725 RPM 1 PHASE
120 VOLT AC ONLY
60HZ 2.0 AMPS
AWARNING
1 Pood maruisl bofore using sow.
2
'Wear safely goggles thai meet ANSI Z37.1 Slandards,
3 Be sure blade is installed with teeth pointing down,
n Keep lingers away from the moving blade.
5. Do no! remove jammed cutoff pieces until blade has
slopped
6. Maintain proper adjustment of blade tension
7. Hold workpiece firmly against the table.
8. Turn power off and wait tor blade to slop before
adjusting or servicing. ....................... ■ , . ,
/CRRFTSMRN
