NOTES:
1. THERE MUST BE [1220 mm] 4 Ft FOR SERVICE AND
FOR UNRESTRICTED AIRFLOW ON ALL SIDES OF UNIT.
2. THERE MUST BE MINIMUM [2440 mm] B ft CLEAR
AIR SPACE ABOVE UNIT.
3. THE APPROXIMATE OPERATING WEIGHT OF THE UNIT IS:
HINGED A(
60 HZ 50 HZ
UNIT WT LBSWT KG
38AK028 1650 748
38AK028C 1804 818
38AK034 1803 818
38AK034C 2009 911
UNIT WT LBSWT KG
38AK028 1650 748
38AK028C 1804 818
38AK034 1803 818
38AK034C 2009 911
[22.2] 7/8
FIELD CONTROL CII
[63.5-92.1] 2 1/2'-3
FIELD MAIN POWER I
APPROX. OPER. WT. (LB.)
AT SUPPORT POINTS
CONTRC
NOTE: “C" INDICATES COPPER COIL.
60 Hz 1 2 3 4 TOT.
028 418 626 242 364 1650
028C 462 666 276 400 1804
034 459 673 272 399 1803
034C 518 719 323 449 2009
50 Hz
025
590 507 590 506 2193
025C 632 542 632 541 2347
030 628 538 628 538 2332
030C 683 586 683 586 2538
Fig. 7 — Dir
