HINGED ACCESS DOOR•
NOTES:
1
3.
THERE MUST BE [1220 mm] 4 ft FOR SERVICE AND
FOR UNRESTRICTED AIRFLOW ON ALL SIDES OF UNIT.
THERE MUST BE MINIMUM C2440 mml 8 ft CLEAR
AIR SPACE ABOVE UNIT.
THE APPROXIMATE OPERATING WEIGHT OF THE UNIT IS:
- A
' II
60 HZ 50 HZ
UNIT WT LBSWT KG
38AK024 1456 661
38AK024C 1580 717
UNIT WT LBSWT KG
38AK024 1456 661
38AK024C 1580 717
CONTROL BOX
NOTE: "C" INDICATES COPPER COIL.
2 4
APPROX. OPER. WT. (LB.)
AT SUPPORT POINTS
60 Hz 1 2 3 4 TOT.
024 411 501 245 299 1456
024C 448 533 273 326 1580
50 Hz
024
587 433 486 358 1864
024c 626 462 518 382 1988
[63.5-92.1] 2 1/2'-:
FIELD MAIN POWER SU
HINGED ACCES
[1315]
4'-3 3/4'
[61]
2 7/16
[19.1]
3/4' dia ;
MOUNTING HOLES
(TYP 4 PLACES)
[63.5-92.1]
2 1/2'-3 5/8'DIA.
FIELD POWER
ENTRY 8 LIFTING
[ 22 . 2 ]
7/8' DIA.
FIELD CONTROL
POWER ENTRY
Fig. 6 — Dimensioi
