Table 3 — Accessories
PART NO.
DESCRIPTION
MODEL
38EB
38CQ900141
HH01AD040
HH93AZ040
HH07AT170
&
HH07AT174
HH93AZ176
HH01AD042
HH93AZ042
HH01YA192
HH93YZ194
38GS900102
38GS900212
HT32BH246
38UE900201
Solid-State Time Guard
(Six 38CQ900152)
r:'
Low-Voltage Control Honeywell Deluxe Thermostat
Thermostat Subbase
Low-Voltage Control
Honeywell Thermostat
Thermostat Subbase
Low-Voltage
Control
Honeywell
Thermostat
Thermostat Subbase
All
Low-Voltage
Control
Grayson
Thermostat
Thermostat Subbase
Indoor Fan Relay (Six HN61KJ210)
Low-Voltage Transformer (Six 38GS900091)
Crankcase Heater*
Crankcase Heater Relay (Six 38UE900212)*
HC95DE088
HN61HB513
Start
Capacitor*
Relay*
015300, 018300
HC95DD121
HN61HB515
Start
Capacitor*
Relay*
024300, 030300
HC95DE066
HN61HB513
Start
Capacitor*
Relay*
036310
HC95DE088
HN61HB515
Start
Capacitor*
Relay*
042360
HC95DE088
HN61HB506
Start
Capacitor*
Relay*
048310
38EB660002
09WQ036,060
38GS900321
Wire Bundle for Start Capacitors and Relays*
Refrigerant-to-Water Heat Exchanger for Chilled Water Systems
All
Liquid Line Filter Drier
28VQ900011
Twelve 3/4- x 1-1/8 in Connection Adapters
048, 060
TUBlNGt
Liquid
PACKAGES
Length
(ft)
OD
(in.)
Tube End
OD (in.)
OD
(in.)
Tube End
OD (in.)
38EB
Evap
Cond
38LS958151
15
3/8
3/8
5/8
3/4**
5/8
38LS958201
20
3/8
3/8
5/8
3/4**
5/8
. 38LS958251
25
3/8
3/8
5/8
3/4**
5/8
38LS958301
30
5/16
3/8
5/8
3/4**
5/8
015, 018, 024
38LS958351
35
5/16
3/8
5/8
3/4**
5/8
38LS958401
40
5/16
3/8
5/8
3/4**
5/8
38LS958501
50
1/4
3/8
5/8
3/4**
5/8
38LS934151
15
3/8
3/8
3/4
3/4
3/4
38LS934201
20
3/8
3/8
3/4
3/4
3/4
38LS934251
25
3/8
3/8
3/4
3/4
3/4
38LS934301
30
3/8
3/8
3/4
3/4
3/4
030, 036
38LS934351
35
3/8
3/8
3/4
3/4
3/4
38LS934401
40
3/8
3/8
3/4
3/4
3/4
38LS934501
50
3/8
3/8
3/4
3/4
3/4
38LS978151
15
3/8
3/8
7/8
3/4
3/4
38LS978201
20
3/8
3/8
7/8
3/4
3/4
38LS978251
25
3/8
3/8
7/8
3/4
3/4
38LS978301
30
3/8
3/8
7/8
3/4
3/4
38LS978351
35
3/8
3/8
7/8
3/4
3/4
38LS978401
40
3/8
3/8
7/8
3/4
3/4
38LS978501
50
3/8
3/8
7/8
3/4
3/4
Suctionj;
*Available thru Carrier Service Parts
tFor maximum capacities, use suction line sizes recommended in
Table 1 Use of accessory tubing packages smaller than recom
mended may result in slight capacity loss (see Note 2)
tSuction line is insulated and has a 90 degree bend at one end
**For 5/8-in evaporator connection, cut off 3/4-in end
NOTES
1
Do not cut 3/8-in OD liquid line toa length shorterthan 10feet
Do not cut 5/16-or 1/4-in liquid line Do not cut 7/8-in OD
suction lines
2
Field-supplied
1-1/8
in
suction
line
is
recommended
on
38EB048 and 060 If accessory tubing package is used, a
capacity reduction can result
