Richland, MI 49083

Tel: (269) 629-5000

Installation & Service Instructions
83-273-000
E18/E28 Slow-Start / Quick Dump
Valve and Accessories

ISSUED: April, 2006
Supersedes: November, 2005

Doc. #83273000, ECN# 060325, Rev. 5

INSTALLATION

1. Refer to the WARNING above.

2. Do not install until you have read the entire product information

sheet.

3. Maximum pressure rating is 150 psig (10.3 bar). Temperature

range is 40°F to 150°F (4.4°C to 65.5°C).

4. Prior to installation, insure that the pressure in the air line

where this product is to be installed is depressurized (0 psig).

5. It is recommended to install an appropriate Wilkerson fi lter

upstream of the unit for maximum trouble free operation.

6. Install with the air fl ow in the same direction as the arrow on the

unit.

7. AVOID restricting the air fl ow with undersize piping or fi ttings,

unless maximum fl ow is not required.

8. Install the valve to the top of the unit. Follow the supplied

instructions with actuating valve for proper installation and
wiring if using an electric solenoid actuating valve.

9. There are two exhaust ports, one in the rear of the unit and one

on the down stream side of the unit cap. INSTALL THE PIPE
PLUG IN THE EXHAUST PORT THAT WILL NOT BE USED.

CAUTION: If plug is not installed securely, plug may
dislodge when valve exhausts and could possibly cause
injury.

10. Install the optional muffl er, if used, in the active exhaust port.

11. Turn the adjusting screw one turn open from fully closed for

initial setting; this will set the slow start portion of the valve at
approximately TEN seconds.

NOTE: Do not over tighten adjusting screw one this could

result in damage to the adjusting screw.

CAUTION: If adjusting screw is backed out until the

threads are disengaged, the adjusting screw could
dislodge when pressure is induced.

12. Apply pressure to the inlet port of the valve.

13. To actuate apply the appropriate voltage signal to actuating

valve. Turn the adjusting screw in 1/8 increments, clockwise
to increase opening time. Turn the needle counterclockwise to
decrease opening time.

NOTE: There will be a slight time delay between the

actuating of the valve and the pressure response due to
resetting of the internal components.

14. Removing the signal voltage from the activating valve will shut

off the supply pressure and depressurize the downstream side
(P2) of the valve.

MAINTENANCE

1. Depressurize the air line prior to attempting any service to the

unit.

2. Remove bottom plug, valve assembly and valve spring. Inspect

all the seals and components for damage and replace as
required. Clean all seals and components using a clean soft
cloth. Lightly lubricate the valve o-ring and bottom plug o-ring
with Magnalube-G lubricant and reassemble in reverse order.

3. Loosen the two screws that retain the top cap and remove it

from the unit. Remove the slide valve from the top cap and the
two pistons and spring from inside the slide valve. Clean all
seals and components of the slide valve pistons. Using a soft
cloth, wipe dry the slide valve, piston and internal bore (in cap).
Lightly lubricate the slide valve o-ring and piston o-rings with
Magnalube-G lubricant.

4. Inspect the top cap for damage and contaminant. Check the

internal fi lter for dogging. If internal fi lter is clogged, replace as
required.

5. Reassemble in reverse order.

6. Remove the needle from the cap and wipe clean. Inspect for

damage and replace as required. Prior to reassembly lubricate
the threads with grease Lubriplate 630-AA or equivalent and
o-ring with Magnalube-G. If needle is damaged, replace cap
assembly.

7. The electric actuating valve solenoid can not be serviced

internally. If the solenoid fails to operate, remove the solenoid
and replace.

!

!

WARNING

To avoid unpredictable system behavior that can cause personal injury
and property damage:

• Disconnect electrical supply (when necessary) before installation,

servicing, or conversion.

• Disconnect air supply and depressurize all air lines connected to this

product before installation, servicing, or conversion.

• Operate within the manufacturer’s specifi ed pressure, temperature,

and other conditions listed in these instructions.

• Medium must be moisture-free if ambient temperature is below

freezing.

• Service according to procedures listed in these instructions.

• Installation, service, and conversion of these products must be

performed by knowledgeable personnel who understand how
pneumatic products are to be applied.

• After installation, servicing, or conversion, air and electrical supplies

(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.

• Warnings and specifi cations on the product should not be covered by

paint, etc. If masking is not possible, contact your local representative
for replacement labels.

!

WARNING

FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED ITEMS
CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY DAMAGE.

This document and other information from The Company, its subsidiaries
and authorized distributors provide product and/or system options for further
investigation by users having technical expertise. It is important that you
analyze all aspects of your application, including consequences of any failure
and review the information concerning the product or systems in the current
product catalog. Due to the variety of operating conditions and applications for
these products or systems, the user, through its own analysis and testing, is
solely responsible for making the fi nal selection of the products and systems
and assuring that all performance, safety and warning requirements of the
application are met.

The products described herein, including without limitation, product features,
specifi cations, designs, availability and pricing, are subject to change by The
Company and its subsidiaries at any time without notice.

EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR INCLUSION
IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE THESE PRODUCTS.
CONTACT YOUR LOCAL REPRESENTATIVE.

!
