Introduction

Follow these instructions when installing, operating, or servicing
the product.

Application Limits

These products are intended for use in general purpose compressed
air systems only.

With Polycarbonate Bowl

kPa

PSIG

bar

Operating Pressure Maximum

1024

150

10.2

Operating Temperature Maximum

52°C (125°F)

Operating Temperature Minimum

0°C (32°F)

With Metal Bowl

kPa

PSIG

bar

Operating Pressure Maximum

1734

250

17.3

Operating Temperature Maximum

80°C (175°F)

Operating Temperature Minimum

0°C (32°F)

ANSI Symbols

Installation

1. The lubricator should be installed with reasonable accessibility

for service whenever possible. Keep pipe or tubing lengths to
a minimum with inside clean and free of dirt and chips. Pipe
joint compound should be used sparingly and applied only to
the male pipe – never into the female port. Do not use PTFE
tape to seal pipe joints – pieces have a tendency to break off
and lodge inside the unit, possibly causing malfunction.

2. Install lubricator so air flows in the direction of arrow on body.

3. Installation should be upstream of the device it is to lubricate

(valve, cylinders, tool, etc.).

Operation and Service

1. The inlet pressure of the Atomist lubricator must be turned

off and depressurized before the fill plug (brass) is removed.
Turn counterclockwise to remove. Fill to oil level line.

Use a petroleum based oil of 100 to 200 SSU viscosity at
100°F and an aniline point greater than 200°F. (Mobil DTE24
and Sun Company Sunvis 932 are good examples). Do not
use oils with adhesives, compound oils containing solvents,
graphite, detergents or synthetic oils.

2. Replace the fill plug (by turning clockwise) and seat firmly.

Excessive torque is not required. Turn on air supply. If leakage
occurs, DO NOT OPERATE — conduct repairs again. The
lubricator is now ready for setting.

Installation & Service Instructions
83-955-000

1/4" and 3/8"
L12 Atomist Lubricators

ISSUED: May, 2005
Supersedes: September, 2002

Doc.# 83955000, ECN# 050500, Rev. 3

Lubricator

with Manual Drain

Lubricator

less Drain

WARNING

To avoid unpredictable system behavior that can cause personal injury
and property damage:

Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.

Disconnect air supply and depressurize all air lines connected to
this product before installation, servicing, or conversion.

Operate within the manufacturer’s specified pressure, temperature,
and other conditions listed in these instructions.

Medium must be moisture-free if ambient temperature is below
freezing.

Service according to procedures listed in these instructions.

Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.

After installation, servicing, or conversion, air and electrical supplies
(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.

Warnings and specifications on the product should not be covered
by paint, etc. If masking is not possible, contact your local
representative for replacement labels.

!

WARNING

FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED
ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY
DAMAGE.

This document and other information from The Company, its subsidiaries
and authorized distributors provide product and/or system options for further
investigation by users having technical expertise. It is important that you
analyze all aspects of your application, including consequences of any
failure and review the information concerning the product or systems in the
current product catalog. Due to the variety of operating conditions and
applications for these products or systems, the user, through its own
analysis and testing, is solely responsible for making the final selection of
the products and systems and assuring that all performance, safety and
warning requirements of the application are met.

The products described herein, including without limitation, product features,
specifications, designs, availability and pricing, are subject to change by
The Company and its subsidiaries at any time without notice.

EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR
INCLUSION IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE
THESE PRODUCTS. CONTACT YOUR LOCAL REPRESENTATIVE.

!

!

CAUTION

Polycarbonate bowls, being transparent and tough, are ideal for use with
Filters and Lubricators. They are suitable for use in normal industrial
environments, but should not be located in areas where they could be
subjected to direct sunlight, an impact blow, nor temperatures outside of the
rated range. As with most plastics, some chemicals can cause damage.
Polycarbonate bowls should not be exposed to chlorinated hydrocarbons,
ketones, esters and certain alcohols. They should not be used in air systems
where compressors are lubricated with fire-resistant fluids such as phosphate
ester and di-ester types.

Metal bowls are recommended where ambient and/or media conditions are
not compatible with polycarbonate bowls. Metal bowls resist the action of
most such solvents, but should not be used where strong acids or bases are
present or in salt laden atmospheres. Consult the factory for specific
recommendations where these conditions exist.

TO CLEAN POLYCARBONATE BOWLS USE MILD SOAP AND WATER
ONLY! DO NOT
use cleansing agents such as acetone, benzene, carbon
tetrachloride, gasoline, toluene, etc., which are damaging to this plastic.

Bowl guards are recommended for added protection of polycarbonate bowls
where chemical attack may occur.
