Vizualogic VW Touareg System - Manual (Page 7)

Part Number:
Description:
Fitment:
Supplier:
Page 7 of 20
7L6 063 500 XXX
Rear Seat Entertainment
Touareg 2004+
Vizualogic
Publish Date: December, 01 2008
Step #08
Center Console Removal:
Now unhook the big white plug as well as the small
black plug.
Step #09
Center Console Removal:
You should be left with the small black plug as well
as the white plug shown in the photo.
Step #10
Center Console Removal:
The A/V Box Main Power harness can now be
connected at this time.
