Vizualogic VW Touareg System User Manual
Page 4
Part Number:
Description:
Fitment:
Supplier:
Page 4 of 20
7L6 063 500 XXX
Rear Seat Entertainment
Touareg 2004+
Vizualogic
Publish Date: December, 01 2008
Step #01
Center Console Removal:
On the drivers side floor, pull up the plastic cover in
the front corner, nearest the center console. Using
a 13mm socket, remove the negative battery cable
from the post.
!
Note:
On the V10 TDI, you will also have to disconnect
the rear battery using a 10mm socket. Simply
remove the negative (-) lead from the battery.
The battery is located under the spare tire in
the rear.
!
Note:
Make sure to protect the negative lead so that
it may not come in contact with metal during
this installation.
!
Note:
Before beginning, make sure painted and trim surfaces are protected to avoid scratching
during installation process of the items. Use proper surface protection covers and work attire
free of dirt and grease.
