Vizualogic VW Touareg System - Manual (Page 6)

Part Number:
Description:
Fitment:
Supplier:
Page 6 of 20
7L6 063 500 XXX
Rear Seat Entertainment
Touareg 2004+
Vizualogic
Publish Date: December, 01 2008
Step #05
Center Console Removal:
Remove the 4 torx screws using a T20 trox driver.
Step #06
Center Console Removal:
Make sure to reinstall the metal retaining clips on
the bezel and set it aside.
Step #07
Center Console Removal:
After the lower panel has been removed, carefully
remove the air vent assembly.
