Vizualogic VW Touareg System - Manual (Page 5)

Part Number:
Description:
Fitment:
Supplier:
Page 5 of 20
7L6 063 500 XXX
Rear Seat Entertainment
Touareg 2004+
Vizualogic
Publish Date: December, 01 2008
Step #02
Center Console Removal:
Remove the bezel on the rear of the center console
by pulling the bottom with a little force.
Step #03
Center Console Removal:
!
Note:
Visually inspect trim panel mounting points
for presence of metal clips. Retrieve with flat
head screw driver and/or replace any that are
missing.
Step #04
Center Console Removal:
Make sure to reinstall the metal retaining clips on
the bezel and set it aside.
