Vizualogic VW Touareg System - Manual (Page 11)

Part Number:
Description:
Fitment:
Supplier:
Page 11 of 20
7L6 063 500 XXX
Rear Seat Entertainment
Touareg 2004+
Vizualogic
Publish Date: December, 01 2008
Step #20
Headrest Installation:
Now move the seat all the way up and forward. This
will allow more room to access the Black plug that
must be removed at this point.
!
Note:
Temporarily reconnect Battery.
Step #21
Headrest Installation:
Now unclip the straps that secure the rear flap onto
the bottom of the seat.
Step #22
Headrest Installation:
With the clips unhooked, the flap should be able to
move as shown in the photo.
This allows you to access the inside of the seat to
pull the cables through.
