Vizualogic VW Touareg System User Manual
Page 20
Part Number:
Description:
Fitment:
Supplier:
Page 20 of 20
7L6 063 500 XXX
Rear Seat Entertainment
Touareg 2004+
Vizualogic
Publish Date: December, 01 2008
Step #47
Finalizing the Install:
Reconnect the negative battery lead to the terminal
post on the drivers’ side floor.
Tighten down the nut with a 13mm socket and
replace the plastic cover.
Step #49
Place the Owner’s Manual and related paperwork
in the glove compartment or give it to the customer
!
Note:
Make sure to test the Vizualogic unit at this time.
INSTALLATION IS NOW COMPLETE
Step #48
Testing: Perform a quick test to make sure
everything is working properly.
1) Insert a DVD.
2)
Make sure images appear on both screens. (Both
monitors must be set to the same source)
3)
Make sure both headphones are working.
(The headphone must be set to the same
channel as the output on the monitor (A or B)).
4)
Make sure the remote control is working.
5) Repeat with second Headrest.
6)
If everything is working, go to step 49.
