VACUUBRAND Exhaust waste vapour condenser Peltronic - Manual (Page 23)

page 23 of 41
Wetted parts
Components Wetted materials
Fittings, hose nozzle ETFE / ECTFE
Cooling surface PP / PFA
Catchpot Borosilicate glass (coated)
O-ring (at catchpot) FEP
Abbreviations
ETFE: Ethylene/Tetrafluoroethylene
ECTFE: Ethylene/Chlorotrifluoroethylene
FEP: Perfluoroethylene perfluoropropylene copolymer
PFA: Perfluoroalkoxylalkane
PP: Polypropylene
Position Component
1 Inlet
2 Outlet
3 Mains connection
4 ON/OFF switch
5 LED
6
Connection plug of the VACUU • BUS line
to the CVC 3000 or VNC 2 (VARIO) controller
7
Jack for connection of VACUU•BUS component
(e.g., level sensor or valve or VMS module)
8 Catchpot
Condenser parts
