SR-C8LWP

SR-C8SWP

Bass-reflex type

Continuous program: 360 W (single-amplifier operation)
Low frequency: 360 W, high frequency: 180 W (bi-amplifier operation)
16 Ω (single-amplifier operation)
Low frequency: 16 Ω, high frequency: 16 Ω (bi-amplifier operation)

98 dB (1 W , 1 m) (single-amplifier operation)

Low frequency: 95 dB (1 W, 1 m), high frequency: 110 dB (1 W, 1 m) (bi-amplifier operation)

65 – 20,000 Hz (when an optional DP-0206 is used)

1,600 Hz (when the optional DP-0206 is used)

Horizontal: 110°, Vertical: 5°

Horizontal: 110°, Vertical: 15°

Low frequency: 20 cm cone type

Low frequency: 20 cm cone type

High frequency: Wave-front control horn

High frequency: Wave-front control horn

110°(horizontal) x 5°(vertical)

110°(horizontal) x 15°(vertical)

+ Compression drivers x 2

+ Compression drivers x 2

Direct cable withdrawal from internal speaker: ø8.6 mm,
conductor cross section: 1.25 m

2

, 4-core cable, 3 m

IPX4

Enclosure: Plywood, black, urethane paint
Mesh grille: Stainless steel, black, paint

526.6 (w) x 293 (h) x 296 (d) mm

526.6 (w) x 293 (h) x 294 (d) mm

17 kg

16 kg

M8 connection bolts ...... 4
Rigging frame: SR-RF8WP
Digital processor: DP-0206

10. SPECIFICATIONS

Model No.
Enclosure
Allowable Input

Rated Impedance

Output Sound
Pressure Level
Frequency Response
Crossover Frequency
Directivity Angle
Internal Speaker

Speaker Cable

Splash-proof Capabilities
Finish

Dimensions
Weight
Accessories
Optional Components

Bass-reflex type
Continuous program: 450 W
8 Ω
93 dB (1 W , 1 m)

40 – 400 Hz (when an optional DP-0206 is used)
80 Hz (when the optional DP-0206 is used)
38 cm cone type
Direct cable withdrawal from internal speaker: ø8.6 mm,
conductor cross section: 1.25 mm

2

, 4-core cable, 3 m

–10˚C to +50˚C

IPX4
Enclosure: Plywood, black, urethane paint
Mesh grille: Stainless steel, black, paint
526.6 (w) x 594.8 (h) x 550 (d) mm
41 kg
M8 connection bolts ...... 4
Rigging frame: SR-RF8WP
Digital processor: DP-0206

Enclosure
Allowable Input
Rated Impedance
Output Sound
Pressure Level
Frequency Response
Crossover Frequency
Internal Speaker
Connected Cable

Ambient Temperature
Range
Splash-proof Capabilities
Finish

Dimensions
Weight
Accessories
Optional Components

10.1. SR-C8LWP and SR-C8SWP

10.2. SR-C15BWP
