7
Base frame
Base frame
Speaker system
Locking screw
Stud screw
3-3. Position the speaker and tighten the three locking
screws.
3-2. After aligning the speaker with the base frame, rotate the
three lock tabs back into position to clamp the speaker to
the base frame. (Temporary fixing state.)
Note
When mounting the speaker, do not touch its paper cone,
as permanent damage to the speaker may result.
3-4. Set the front grille's aiming marker to the speaker front
(i.e. speaker orientation) so that the three stud screws
align with the corresponding stud receptacles, then
push the grille onto the speaker.
Aiming marker
Stud screw Speaker front
Stud receptacle
