Toa CR-413 - Manual (Page 6)

6
3.2. CR-413 (41-Unit size)
Mountable depth from the panel mounting surface is 410 mm (16.14"). (402 mm or 15.83" to rear
reinforcement bracket)
ø6.5 (0.26) Knockout hole for fixing to a wall
4-ø12 (0.47) Knockout hole for multiple rack support
4-ø15 (0.59) for anchor bolt
Height adjustment screw
(accessible from inside)
33 (1.3)
33 (1.3)
82 (3.23)
2000 (78.74)
338 (13.31)
280
(1
1.02)
175
(6.89)
10 (0.39)
40 (1.57)
20 (0.79)
566 (22.28)
470 (18.5)
360
(14.17)
11
5
(4.53)
220
(8.66)
100
(3.94)
89 (3.5)
1649 (64.92)
435 (17.13)
200
(7.87)
440 (17.32)
4-ø17.5 (0.69) Eyebolt mounting hole (with a hole plug)
Cable entry opening
Cable entry
opening
Unit: mm (inches)
