2. CONFIRMING INCLUDED PARTS
Refer to the tables below to check quantity of each part before assembling the cabinet rack.
Notes
• Assemble the parts into a complete rack while checking the name label attached to each part and screw.
For covers, the name labels are on their backsides.
• Be sure to use the specified screws to mount the components in the rack.
2.1. Complete Parts
2.2. Screws
2.3. Accessories Other Than Screws
Quantity
CR-413
1
1
1
1
1
1
4
2
1
1
1
1
1
3
Part name
Top plate
Base
Front right frame
Front left frame
Rear right frame
Rear left frame
Side reinforcement bracket
Rear reinforcement bracket
Top cover
Side cover (right)
Side cover (left)
Base cover (front)
Base cover (rear)
Rear cover
CR-273
1
1
1
1
1
1
2
1
1
1
1
1
1
2
Quantity
CR-413
60 (56)
20 (14)
30 (24)
Screw type
Bind head taptite screw type B 5 x 12
Bind head taptite screw type B 4 x 10
Bind head screw M4 x 8
CR-273
50 (44)
20 (14)
20 (16)
( ) = Quantity to be actually used.
Quantity
CR-413
2 (190 cm)
8
20
Accessory
Screw cover
Screw cover rail
Cable tie
CR-273
2 (130 cm)
6
12
