18
5.3. Securing to Wall
A ø6.5 mm (0.26”) knockout hole is provided in the top cover of the rack. (See pages 5 and 6.)
Remove the knockout with a screwdriver, and secure the top cover to a wall using the bracket (separately
prepared).
[Example]
5.4. Securing Multiple Racks in Line
Two ø12 mm (0.47”) knockout holes are provided in each side cover. (See pages 5 and 6.) When installing
multiple racks in line, remove these knockout holes with a screwdriver, then connect each adjacent racks
using M8 bolts and nuts.
Bolt *
M6 bolt *
Bracket *
Anchor *
Knockout hole (ø6.5 mm or 0.26”)
Plain washer for M6 *
Nut for M6 *
Top cover
for the CR-273 or CR-413
* Commercial items
