21
11. SPECIFICATIONS
11.1. FS-7006PA/7012PA Power Amplifiers
FS-7006PA FS-7012PA
230 V AC, 50 Hz
1,090 W (1,540 VA) (at rated output), 2,130 W (2,670 VA) (at rated output),
390 W (600 VA) (IEC 65), 750 W (950 VA) (IEC 65),
58 W (110 VA) (at no signal), 58 W (110 VA) (at no signal),
13 W (14 VA) (standby) 13 W (14 VA) (standby)
0 dB*, 10 kΩ, transformer-balanced, removable terminal block (3 pins)
600 W 1,200 W
100 V line, 16.7 Ω, M4 screw terminal, 100 V line, 8.3 Ω, M4 screw terminal,
distance between barriers: 9 mm distance between barriers: 9 mm
80 – 15,000 Hz, within ±3 dB (1 kHz)
Under 0.1% (at 1 kHz rated output)
Over 90 dB, 20 – 20,000 Hz band pass
Volume control bypass control input: no-voltage make contact input,
open voltage: Under 24 V DC, short-circuit current: Under 10 mA,
removable terminal block (2 pins)
Power (green), Signal (green), Peak (red), Fault (red), Bypass (orange)
Forced air cooling (Under 50°C: Stop, 50 – 75°C: Low to high speed (variable),
Over 75°C: High speed)
0°C to +40°C
Under 90% RH (no condensation)
Panel: Aluminum, black, alumite
482 (w) x 132.6 (h) x 532.7 (d) mm
24.8 kg 35.4 kg
Model No.
Power Source
Power Consumption
Input
Rated Output
Load Impedance
Frequency Response
Distortion
S/N Rated
Control Input
Indicator
Cooling
Operating Temperature
Operating Humidity
Finish
Dimensions
Weight
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Terminal cover ........................................... 1
Machine screw M4 x 8 ............................... 2 Removable terminal plug (2 pins) .............. 2
Removable terminal plug (3 pins) .............. 2
