Figure 2 – Tii ELP-2 Series User Manual
Page 3
TII P/N: 92229801
MATING TABS
BLACK -V IN
RED +12V IN
SIGNAL RETURN
ON BATTERY
REPLACE BATTERY
MISSING BATTERY
LOW BATTERY
1
2
3
4
PHONE LINE CONNECTIONS
T (TIP) - GRN R (RING) - RED
PHONE
TEST JACKS
VIDEO
OUTPUT
ETHERNET
HUB JACK
ELP-2A
FIBER INPUT
10 AWG GROUND WIRES
22 AWG GROUND WIRES
SFH ONT 611
CUSTOMER
FIGURE 2
ELP-2B
CUSTOMER
MDU PROTECTED
OUTPUTS
