Configuration 4-9
■
If the utility voltage frequently varies outside the UPS operating range
(see Fig 4-6), consider changing from normal to extended range
(+20% to –35%). This provides more tolerance to brief utility voltage
fluctuations.
To update the nominal voltage and operating range parameters:
1.
Have a qualified electrician monitor utility voltage.
2.
Use the following tables to identify the operating range that most closely
matches requirements:
Table 4-2
Operating Ranges (VAC) - T2000 and T2000j Models
Nominal Level
Normal Range
Extended Range
100
80 to 120
Not applicable
110
88 to 132
72 to 132
120
96 to 144
78 to 144
127
102 to 152
83 to 155
Table 4-3
Operating Ranges (VAC) - T2000h and T2000h-NA Models
Nominal Level
Normal Range
Extended Range
208
166 to 250
Not applicable
220
176 to 264
143 to 264
230
184 to 276
150 to 276
240
192 to 288
156 to 288
3.
For nominal voltage level setting, select configuration parameters
1, 2, 3, or 10 (see Table 4-1).
4.
Access parameter 4 to switch from normal to extended range (see
Table 4-1).
