Tii 442 User Manual
Page 2
To Existing
AC Wiring
To AC Power Plug
To Auxiliary Ground
Mounting Tab
Screw
3. Unscrew the grounding wire terminating screw
until the grounding wire can be inserted (See
Figure 1).
4. Strip back about 0.5 inch of insulation from the
grounding wire. Insert the grounding wire into
the grounding port hole. Tighten terminating
screw (See Figure 1).
NOTE: INSTALLATION OF THE MODEL TII 442
MUST BE IN ACCORDANCE WITH THE LOCAL
CODES AND ARTICLE 800 OF THE NATIONAL
ELECTRIC CODE, ANSI/NFPA 70.
CAUTION: NEVER INSTALL THE TII 442
DURING A LIGHTNING STORM. THE TII 442 IS
INTENDED FOR INDOOR USE ONLY.
Figure 2
