Tie Down Jet Rail XL - Manual (Page 2)

Part # Stock # Description Qty.
1 26617 Jet Rail Frame Tube (72” long, 3x4) 1
2 26606 Jet Rail Carriage (20” long) 1
3 26615 Jet Rail Rear Deck Mount 1
4 26608 Jet Rail Front Deck Mount 1
4a 26618 Front Brace 1
5 26614 Jet Rail Deck (47” long) 1
6 26610 Winch Mount Extension Tube (42” long, 2x3) 1
7 26611 Winch Mount 1
8 26612 Bow Stop 1
9 26613 Winch Mount Tube 1
10 44816 Carpeted Bunk, 5’ 2
10a 48667 Bunk Slicks 2
11 17057 Keel Pad 6” Long 3
12 50460JR Winch Strap, 15’ 1
13 17135 Brake Winch, 1200 lb. 1
HARDWARE
14 45245 Bushing, 4” 7
15 45246 Bushing, 1” 2
16 45251 Winch Strap Roller 1
17 44610 1/2” x 5-1/2” Rod 5
18 86116 Swivel Bracket 6
19 17085 2” End Cap 4
20 10605 Safety Locking Pin 1
21 BBPELLNUT500 1/2” Pal nut 12
21a BBPELLNUT625 5/8” Pal Nut 2
22 10602 Hair Cotter Pin 1
23 17052 Spool Roller 4” 2
24 10904 Self-Tapping Screw, #10 x 3/4” 6
25 10903 Self-Tapping Screw, #14 x 1-1/2” 12
26 84472z 1/2” U-Bolt 2
27 10538 3/8” x 1” Hex Head Bolt 11
28 BBB3750400 3/8” x 4” Hex Head Bolt 7
Note: Three of the 3/8” x 4” hex head bolts are grade 5 bolts, used on page 4, section 5.
29
10537 3/8” x 3” Winch Bolt 1
30 10938 1/2” x 5-1/2” Hex Head Bolt 2
31 10936 1/2” x 7” Hex Head Bolt 1
32 10937 1/2” x 8-1/2” Hex Head Bolt 2
33 10645 1/2” Nyloc Nut 9
34 10627 3/8” Nyloc Nut 25
35 10504 1/2” Nylon Flat Washer 28
36 B58-15208 Nylon Bushing 17
37 10573 1/2” Washers 4
38 44540 Shackle Plate 1
39 10804 3/8” x 1” Carriage Bolt 3
40 10630 Stainless Steel Screws 8
42 44611 1/2” x 6-1/2” rod 1
43 45247 1/2” ID x 5.5” Bushing 1
4 color
