• One person launch n' load • Easy assembly • Nothing else to buy
• Small "footprint", takes up less room on dock
The Jet Rail is an all galvanized steel PWC lift designed for easy one person "launch and load".
The small foot print under the ski allows easy walk around while the watercraft is stored on
the dock or seawall. The 800 lb. brake winch and mount adjusts to any size watercraft and
slides inside the lift when not in use, saving even more precious dock space. Carpeted bunk
boards and all hardware are included. All you add is your PWC!
Model Stk # UPC Code Shipping Wt.
Jet Rail 27277 0 08162827277 2 166 lbs
9.
6
5.
Specifications 4/8/98
1. Weight without PWC 161 lbs
2. Length with extension in 7'-1"
3. Length with full extension 10'-4"
4. Width without PWC 21-1/2"
5. Width of dock mounting hdw. 18"
6. Length between dock mounting hdw 6'
7. Winch capacity 800 lbs
8. Winch strap length 15'
9. Height without PWC at winch 36"
10. Height without PWC at bunk rail 19"
11. Maximum space between edge 2.5"
of dock and rear dock mount
12. Bunk Length 5'
13. Max. ht. from water to dock mount 22"
Capacities
Weight of PWC 650 lb (or capacity of dock,
whichever is less)
Width of PWC (Determined by dock space)
Length of PWC 10'-2"
For additional information , contact Customer Service at 1-800-241-1806.
Assembly Time: Approximately 90 minutes
Tools required: Hammer, 9/16" Wrench,
3/4" Wrench, Ratchet, 9/16" Socket,
3/4" Socket, 3/8" Socket, Phillips Screw Driver
The Jet Rail was not designed for alterations such as electric winches, roller bunks
or modifications to the existing parts.
9
Shipping Boxes
Box one: Dimensions 43" x 50" x 7-1/4", wt. 66 lbs.
Box two: Dimensions 8-1/2" x 4-1/2" x 74", wt. 46 lbs.
Box three: Dimensions 22-1/4" x 8" x 48-1/4", wt. 54 lbs.
