T RAMLINING RHYTHMS LH ”I NTELLITRAM ” 500 O PERATORS MANUAL
30 LH A GRO
Rhythm 50 Left:
6 m seed drill/15 m equipment or 8 m seed drill/20 m equipment.
Shut off = 2 x right & 2 x left side, start the field on the left-hand side.
01
02
03
04
05 06
07
08
09
10
Rhythm 51 Right:
6 m seed drill/15 m equipment or 8 m seed drill/20 m equipment.
Shut off = 2 x right & 2 x left side, start the field on the right-hand side.
10
09
08
07
06 05
04
03
02
01
Rhythm 52 Left:
4 m seed drill/18 m equipment or 6 m seed drill/27 m equipment.
Shut off = 2 x right & 2 x left side, start the field on the left-hand side.
01 02
03
04 05 06
07
08 09
10 11
12
13 14 15
16
17 18
Rhythm 53 Right:
4 m seed drill/18 m equipment or 6 m seed drill/27 m equipment.
Shut off = 2 x right & 2 x left side, start the field on the right-hand side.
18 17
16
15 14 13
12
11 10
09 08
07
06 05 04
03
02 01
