T RAMLINING RHYTHMS LH ”I NTELLITRAM ” 500 O PERATORS MANUAL
28 LH A GRO
Shut off = right side, start the field on the left-hand side.
01 02 03 04
05 06
07 08 09 10
Rhythm 12 left/right:
Shut off = left side, start the field on the left-hand side.
01 02 03 04 05
06 07
08 09 10 11 12
Shut off = right side, start the field on the right-hand side.
12 11 10 09 08
07 06
05 04 03 02 01
Rhythm 14 left/right:
Shut off = right side, start the field on the left-hand side.
01 02 03 04 05 06
07 08
09 10 11 12 13 14
Shut off = left side, start the field on the right-hand side.
14 13 12 11 10 09
08 07
06 05 04 03 02 01
Rhythm 16 left/right:
Shut off = left side, start the field on the left-hand side.
01 02 03 04 05 06 07
08 09
10 11 12 13 14 15 16
Shut off = right side, start the field on the right-hand side.
16 15 14 13 12 11 10
09 08
07 06 05 04 03 02 01
