LH ”I NTELLITRAM ” 500 O PERATORS MANUAL S YSTEM
LH A GRO 23
TEST
TEST INPUT
Test input can be used if
Directly under each input description, to the right, is a counter that registers the
number of time the input has been activated (the counter is reset automatically
each time “Test input” is exited or by pressing the C key). On the left-hand side
the actual status of the input is shown (Hi/Lo).
All of the different inputs can been seen by pressing the ARROW UP and ARROW
DOWN keys to page through the 3 screens.
The different input descriptions relate to the following:
Input Description
Wheel/tractor Forward speed signal from the sensor fitted on the tractor.
Radar
Forward speed signal from the radar fitted on the tractor.
Wheel
implement Forward speed signal from the sensor fitted on the seed drill.
Press the ARROW DOWN key to see the next inputs:
Implement
sensor/tractor Implement signal (area on/off) from the implement sensor fitted on
the tractor (via the 7-pin DIN/ISO plug in the tractor).
Impl. sensor
/implement Implement signal (area on/off) from the implement (seed drill).
Clutch left /fan
Signal from the RPM sensor fitted to the left clutch or signal from
the RPM sensor fitted to the fan on pneumatic machines.
Press the ARROW DOWN key to see the next inputs:
Clutch right Signal from the RPM sensor fitted to the right clutch.
Drill shaft Signal from the RPM sensor fitted on the drill shaft.
Level sensor Signal from the hopper lever sensor.
TEST OUTPUT
Each individual output can be tested. Press the program key number for the
following test:
Output Description
Left clutch 1
Activation of the left clutch or signal to open the left valve on
pneumatic seed drills.
Left clutch 2 Signal to close the left valve on pneumatic seed drills.
Right
clutch 1
Activation of the right clutch or signal to open the right valve on
pneumatic seed drills.
Right
clutch 2 Signal to close the right valve on pneumatic seed drills.
