LH 1200 O PERATORS & F ITTING MANUAL O PERATING THE LH 1200
LH A GRO 13
SECONDARY FUNCTIONS; SLURRY SPREADER
APPLICATION RATE MONITORING
Flow metering is possible on slurry spreaders either by using a flow meter
(electromagnetic) or by a RPM sensor fitted to a positive displacement pump
(exact volume per revolution).
By encoding an amount in kilos (with 2 decimals) per impulse as a flow figure the
following functions are available:
ENCODE:
XXXX is the known calibration figure in kg with
2 decimals. 5.00 kg is encoded as 500 The
application rate will be shown as m
3 /ha.
Key Function
Slurry application rate
Total slurry consumption
NOTE!
It is a condition for correct operation of the above functions that the flow
sensor is calibrated.
SECONDARY FUNCTIONS, BALER
UNIT COUNTER
It is possible to count the number of bales baled. Encoding a flow figure of 9999
and pressing the L key enables the unit counter.
ENCODE:
Press the shown keys in this order.
Key Function
Units:
NOTE!
The L/MIN key and the L key cannot be used when this
encodement is used.
