Bulletin 98-01122
R3
1
SHIFT
CTRL
2ND
ALT
CAPS
CHG
LOW
BAT
COMPACTFLASH CARD 256MB
San Disk
256
MB
CompactFlash
BACKLIGHT DIM
LIGHTBAR DIM
CENTER SCREEN
BACKLIGHT BRIGHT
LIGHTBAR BRIGHT
BACKLIGHT ON/OFF
UP ARROW
DOWN ARROW
ENTER
RIGHT ARROW
LEFT ARROW
EXIT
FIELDWARE for SMARTPAD II
Quick Start Guide
DATA ENTRY
TOUCH SCREEN SELECTION
To make a selection use a stylus and single tap the screen on the desired menu.
MANUAL SELECTION
Items can only be selected when highlighted. Use the Up and Down arrows to
highlight the desired selection. Press Enter to select.
SCREEN SELECTION
ON-SCREEN KEYBOARD ENTRY
Select the desired menu to be changed. Select the Keyboard icon to bring up the on
screen keyboard. This icon will appear is the upper left corner of the screen only when
text can be entered. Select the desired character using a stylus and press Enter to
accept.
MANUAL ENTRY
Select the desired menu to be changed, and use the Up and Down arrows to
change the character. Use the Left and Right arrows to advance to the next
character. Press Enter to accept.
