TECHNOLOGIES 834-P Sprayer Control
3 98-70028-R0
Normal Working Mode (GPT Mode)
Note: This section covers operation of the 834-P in Gallons Per Ton mode.
Operating instructions for Gallons Per Acre mode can be found on page 6.
I
NTRODUCTION
In the Gallons Per Ton (GPT) normal working mode, the display can show three different
pieces of information indicated by the LED’s below the display e.g.:
Application rate in GPT
Shaft RPM
Pressure in PSI
Use of the keys during normal working mode is summarized as follows:
key is used to power ON and to select the information display
Auto/Man & key combination is used to power OFF (when not spraying)
+
and keys are used for changing the target application.
In manual mode the
+
and keys drive the regulating valve to adjust pressure.
T
ARGET
A
PPLICATION
R
ATE
D
ISPLAY
In this display the application rate in gallons per ton
(GPT) is shown. The target application rate will be
displayed any time the master boom switch is in the
off position (a "t" is on the display when the target
application rate is displayed). When the master
switch is on, no “t” is on the display and the actual
application rate is displayed.
Press the
+
or keys to select another target
application rate. This can be done before the
spraying operation begins with the Master
switch off or can be done on the go while spraying
in Auto mode.
Press the key to advance to the speed/rpm display.
t20.0
tip
select
GPA
GPT
SPEED
RPM PSI
On
Inch
lbs/rot
PROGRAM MODE push 3 sec.
Gal/min
@40 psi
P/300ft
P/rot
MPH
RPM
min
