I N S T R U C T I O N M A N U A L • M O D E L 2 0 5 0 / 2 0 5 5
23
To remove the pinch point cover:
a. Loosen and remove the cover’s 4 screws - 2 on each side of the cover.
b. Pull the cover to the front and then pull it down and off as shown below.
MODEL 2055 COVER REMOVAL
To remove the side panel cover:
a. Maintain air pressure and unplug the power supply from the electrical
source.
b. Loosen and remove the 4 Phillips pan head screws - 2 on the top of the
cover and 2 on the bottom. (See photo on the next page.)
PINCH POINT
COVER
SCREWS
Always disconnect the
power supply from the
electrical source before
removing covers.
