Sonics VCX134 - Manual

USER’S GUIDE
AUTOTUNE SERIES
HIGH INTENSITY ULTRASONIC PROCESSOR
MICROPROCESSOR CONTROLLED
100 Watt Model
• 130 Watt Model
TABLE OF CONTENTS
Warranty
Important Safeguards
Low Surface Tension Liquids - Organic Solvents
SECTION 1 – INSTALLATION
Inspection
Electrical Requirements
Installing the Ultrasonic Processor
SECTION II – OPERATION
Principles of Ultrasonic Disruption
Functions of Controls, Indicators, and Connectors
Preparations for Use
Using the Ultrasonic Processor
SECTION III – SERVICE INFORMATION
Overload Condition
Return of Equipment
SECTION IV – OPERATING SUGGESTIONS AND TECHNIQUES
The Ultrasonic Processor supplied with this instruction manual is constructed of the finest
material and the workmanship meets the highest standards. It has been thoroughly tested
and inspected before leaving the factory and when used in accordance with the
procedures outlined in this manual, will provide you with many years of safe and
dependable service.
Rev. April 2004
