SerialGate User Guide
62
Chapter 7. Configuration via LCD
This feature is for SG-2xx0 model only.
Through the LCD on the front panel, a user is able to test operation of each interface and configuration.
By default, the LCD displays communication status of each port, and by operating the keys next to the
LCD, the interface can be tested.
LCD and Key Operation
The LCD screen can display 16 characters with 2 lines. Four buttons are there to configure the operating
environment.
The function of each key is as follows.
Key 기능
MENU /
OK
Go to sub-menu from the current menu / Menu entry / Setting mode entry / Set /
Select

Go to the previous menu / Move to previous item / Raise the number of IP mode
 Go to the next menu / Next item / Reduce the number of IP mode

Go to the high-level menu / Change the settings in the setup mode, or move the
cursor to the left

Go to the low-level menu / Menu entry / Setting changes to take effect / Change
the settings in the setup mode, or move the cursor to the right
