Solvline SG-2xxx Series - Manual (Page 46)

SerialGate User Guide
46
Menu Default Descriptions
Interface
RS232,
RS422
RS485
In RS232 model, default is set to RS-232.
In combo model, it is selectable between RS-422, RS-485 (No-Echo)
and RS-485 (Echo). Default value is RS-422.
In ALL model, it is selectable between RS-232, RS-422, RS-485(No-
Echo) and RS-485(Echo). Default value is RS-232.
In SG-1160/ALL model, it is selectable between RS-232, RS-422,
RS-485 (No-Echo) and RS-485 (Echo). Default value is RS-232 and
termination can be configured.
Local
Socket Port
4001
Set the socket number for the port. TCP server and UDP server
operation mode makes use of this port for awaiting network socket
connections.
Port Alias Port1 Name each port for convenience. 16 Characters at maximum.
Baud Rate 9600 bps
Set communication speed
(Options: 150, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400,
57600, 115200, 230400, 460800, 921600 bps)
Data Bits 8
Set the number of bits in each character size.
(Options: 5, 6, 7, 8)
Stop Bits 1
Set the number of stop bits.
(Options: 1, 2)
Parity None
Set parity bit check scheme.
(Options: None, Odd, Even)
Flow
Control
None
Set the flow control scheme.
(Options: None, Xon/Xoff, RTS/CTS)
Device Type DataOnly
Set the signal line checking method for the device to be connected to
the given serial port.
If the mode is set to Data Only, TxD, RxD, and GND signal lines are
used in inter-device communication.
If the mode is set to Modem Signals, all modem signals except RI
(Ring Indicator) are asserted, tested, and used in communication.
(Options: Data Only, Modem Signals)
Remote IP
Address /
Port
0.0.0.0 /
4000
If the Operation Mode is in TCP Client or UDP Client or Pair_Master
mode, set the IP address and the socket number to connect to.
