Solvline SG-2xxx Series - Manual (Page 34)

SerialGate User Guide
34
Connecting to SerialGate
In order to view current settings or modify them, you need to make a Web or Telnet connection to
SerialGate. IP address is required information to make a connection.
There are two ways you can know the current IP address of SerialGate.
If WAN port in SerialGate uses assigned IP address from DHCP server or is set to a fixed IP address,
SerialGate supports the following options in case that a user does not know IP address.
For SG-204x/208x/216x Series
1. A user can connect to the default LAN port with IP address: 10.10.1.1
2. A user can search IP address pre-set to SerialGate using “Detector” application enclosed in Utility and
Documents CD and connect to SerialGate.
Default WAN IP Address: 192.168.0.223
The default IP address of SerialGate is set to 192.168.0.223. In order
to connect with this address, you need to change network
configurations so that your PC can connect to the IP 192.168.0.223.
Please refer to an example to the right side, and note that values do
not necessarily have to be identical to the example below.
Default LAN IP Address: 10.10.1.1
For SG-201x/202x , LAN port’s IP address is 10.10.1.1 while LAN port’s
default IP address for SeroalGate-204x/208x/216x is 10.10.1.1. In
order to connect with this address, you need to change network
configurations so that your PC can connect to the IP 10.10.1.1. Please
refer to an example below, and note that values don ’t necessarily have
to be identical to the example below.
