SerialGate User Guide
15

Serial Port: DB-9 male (DE-09P) or RJ-45 socket for serial ports

DC-Jack power connector: for connection of 12~48VDC adapter cable
When the power is supplied from the both terminal block and DC adapter connector
at the same time, it may cause irreparable damage to the product.

Terminal block power connector: for connection of 12~48VDC terminal block cable
When the power is supplied from the both terminal block and DC adapter connector
at the same time, it may cause irreparable damage to the product.

Reset button: SerialGate reboots if this button is pressed for less than 3 seconds. If pressed
for longer than 3 seconds, SerialGate will restore its factory default settings.

LED: Operation status of SerialGate. Next section describes the meaning of each LED
display status.

LAN port: 8-pin RJ45 jack connects SerialGate to networking devices such as Ethernet card,
hub, and router.
