SerialGate User Guide

32

Pin Specification (DB-9 male / DE-09P)

Pin No.

RS-232

RS-422

RS-485

1

DCD

-

-

2

RXD

RxD +

-

3

TXD

TxD +

TRxD +

4

DTR

-

-

5

GND

GND

GND

6

DSR

RxD -

-

7

RTS

TxD -

TRxD -

8

CTS

-

-

9

Power(Option)

Power(Option)

Power(Option)
